Image Sensor
|
1/2.8 inch Progressive Scan CMOS
|
|
Min. Illumination
|
Color: 0.005 Lux @ (F1.8, AGC ON)
B/W: 0.001 Lux @ (F1.8, AGC ON)
|
|
Day & Night
|
ICR
|
|
Focus Mode
|
Auto / Semiautomatic / Manual
|
|
Shutter Time
|
50Hz: 1~1/30,000s; 60Hz: 1~1/30,000s
|
|
S/N Ratio
|
>52dB
|
|
Digital Zoom
|
16x
|
|
White Balance
|
Auto/ Manual/ ATW/ Indoor/ Outdoor/ Daylight lamp/ Sodium lamp
|
|
AGC
|
Auto / Manual
|
|
Focal Length
|
8-250mm, 32x
|
|
Angle of View
|
33.4-1.1 degree (Wide-Tele)
|
|
Min. Working Distance
|
10-1500mm (Wide-Tele)
|
|
Aperture Range
|
F1.8-F6.1
|
|
Main Stream
|
50Hz: 25fps (1920 x 1080), 25fps (1280 x 960), 25fps (1280 x 720)
60Hz:30fps (1920 x 1080), 30fps (1280 x 960), 30fps (1280 x 720)
|
|
Sub Stream
|
50Hz: 25fps (704 x 576), 25fps (352 x 288), 25fps (176 x 144)
60Hz: 30fps (704 x 480), 30fps (352 x 240), 30fps (176 x 120)
|
|
Third Stream
|
50Hz: 25fps (1920 x 1080), 25fps (1280 x 960), 25fps (1280 x 720), 25fps (704 x 576), 25fps (352 x 288), 25fps (176 x 144)
60Hz: 30fps (1920 x 1080), 30fps (1280 x 960), 30fps (1280 x 720), 30fps (704 x 480), 30fps (352 x 240), 30fps (176 x 120)
|
|
Image Compression
|
H.264 (Baseline, Main, High Profile)/ MJPEG/ MPEG4
|
|
Audio Compression
|
G722.1/G.711ulaw/G.711alaw/MP2L2/G.726
|
|
SVC
|
Support
|
|
ROI
|
Support 24 areas with adjustable levels
|
|
Protocols
|
IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP,UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE
|
|
Standard
|
ONVIF, PSIA, CGI
|
|
Others
|
Defog, EIS, Privacy Mask, 3D DNR, BLC, WDR
|
|
IR Distance
|
800m
|
|
IR Intensity
|
Automatically adjusted, depending on the zoom ratio
|
|
Smart IR
|
Support
|
|
Movement Range
|
Pan: 360º endless, Tilt: +40º ~ -90º
|
|
Movement Speed
|
Pan: 0.1º-100º/s, Tilt: 0.1º-40º/s
|
|
Number of Preset
|
256
|
|
Patol
|
8 patrols, up to 32 presets per patrol
|
|
Pattern
|
4 patterns, with the recording time not less than 10 minutes per pattern
|
|
Power-off Memory
|
Support
|
|
Park
|
Support
|
|
Proportional Zoom
|
Support
|
|
PTZ Position Display
|
On / Of
|
|
Menu
|
Chinese/ English
|
|
3D Positioning
|
Support
|
|
Preset Freezing
|
Support
|
|
Scheduled Task
|
Support
|
|
Alarm I/O
|
7 alarm inputs, 2 alarm outputs, alarm linkage
|
|
Alarm Action
|
Preset / Patrol / Pattern / SD card recording/ Aux output/ E-map on Client
|
|
Audio I/O
|
1/1
|
|
Ethernet
|
10Base-T / 100Base-TX, RJ45 connector
|
|
CVBS Output
|
1.0V[p-p] / 75Ω, NTSC (or PAL) composite, BNC
|
|
RS485
|
Half duplex, Pelco-P, Pelco-D, self-Adaptive
|
|
Onboard Storage
|
Built-in Micro SD/SDXC card slot, up to 32GB; edge recording
|
|
Simultaneous live view
|
Up to 10
|
|
User/Host Level
|
Up to 32 users, 3 Levels: Administrator, Operator and User
|
|
Power
|
24 VAC, Max.90W
|
|
Protection level
|
IP66 standard (outdoor dome), TVS 6,000V lightning protection, surge protection and voltage transient protection
|
|
Dimensions
|
251 x 508 x 360 mm
|
|
Weight
|
15kg
|
