| Image Sensor |
1/2.8 inch Progressive Scan CMOS |
| Min. Illumination |
0.01 Lux @(F1.2,AGC ON), 0 Lux with IR |
| Shutter Speed |
1/3 s to 1/100,000 s, support slow shutter |
| Lens |
4mm, horizontal field of view: 83° (6mm: 55°, 8mm: 38.5°, 12mm: 24.6°, optional) |
| Lens Mount |
M12 |
| Day & Night |
IR cut filter with auto switch |
| DNR |
3D DNR (Digital Noise Reduction) |
| Wide Dynamic Range |
Digital WDR |
| Video Compression |
Main stream: H.264 |
| Sub stream: H.264, MJEPG |
| H.264 Type |
Baseline Profile/Main Profile |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| Dual Streams |
Support |
| Max. Resolution |
1920 x 1080 |
| Main Stream |
50Hz: 1920 x 1080,1280 x 960,1280 x 720 @25fps |
| Max. Frame Rate |
60Hz: 1920 x 1080,1280 x 960,1280 x 720 @30fps |
| Sub-stream |
50Hz: 704 x 576, 640 x 480, 352 x 288, 320 x 240 @25fps |
| Max. Frame Rate |
60Hz: 704 x 480, 640 x 480, 352 x 240, 320 x 240 @30fps |
| Image Settings |
Brightness, saturation, contrast, sharpness are adjustable via web browser or client software |
| Day/Night Switch |
Support auto, scheduled, and triggered by alarm input |
| Others |
Mirror, BLC (area configurable), Region of Interest (support 1 fixed region) |
| Detections |
Motion Detection, Dynamic Analysis |
| Alarms |
Video Tampering, Network Disconnected, IP Address Conflicted, HDD Full, HDD Error |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| Standard |
ONVIF (PROFILE S,PROFILE G), PSIA, CGI, ISAPI |
| General Function |
Anti-Flicker, Heartbeat, Mirror, Password Protection, Privacy Mask, IP Address Filter, Watermark |
| Communication Interface |
1 RJ45 10M/100M self-adaptive Ethernet port |
| Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F), Humidity 95% or less (non-condensing) |
| Power Supply |
12VDC ± 25%, PoE (802.3af) |
| Power Consumption |
Max. 3.5W |
| IR Range |
30 meters |
| Protection Level |
IP67 |
| Dimensions |
147.5 x 78.2 x 92.9mm |
| Weight |
350g |
