| Image Sensor | 5MP CMOS Image Sensor |
| Effective Pixels | 2592(H) x 1944(V) |
| Min. illumination | Color: 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Shutter Time | 1/25(1/30)s to 1/50,000s |
| Lens | 2.8-12mm motorized vari-focal lens |
| Lens Mount | φ14 |
| Day & Night | IR cut filter with auto switch |
| Angle Adjustment | Pan: 0º – 360°, Tilt: 0 – 90°, Rotation: 0 – 360° |
| Synchronization | Internal synchronization |
| Wide Dynamic Range | 120dB |
| Video Frame Rate | 2592 x 1944@20fps |
| HD Video Output | 1 Analog HD output |
| Menu | |
| D/N Mode | Auto/ Color/ B/W |
| Auto White Balance | Auto/MWB |
| BLC | Support |
| AGC | Support |
| Language | English/Chinese |
| Function | Brightness, Sharpness, Digital noise reduction, Mirror, Bad pixel correction, Smart IR |
| General | |
| Operating Conditions | -40 °C – 60 °C (-40 °F – 140 °F) |
| Humidity 90% or less (non-condensing) | |
| Power Supply | 12VDC±20% |
| Power Consumption | Max. 6W |
| Protection Level | IP67 |
| IR Range | 40 meters |
| Communication | Up the coax |
| Protocol: HIKVISION-C (Coaxitron) | |
| Dimension | 92 x 84.8 x 269.6 mm |
| Weight | Approx. 900 g |
