1/3 inch Progressive Scan CMOS
|
|
Effective Pixels
|
2048 x 1536
|
|
Signal System
|
PAL/NTSC
|
|
Minimum Illumination
|
Color: 0.05 lux @ f/1.4, AGC on; B/W: 0.01 lux
|
|
White Balance
|
Auto/ Manual/ ATW/ Indoor/ Outdoor/ Daylight lamp/ Sodium lamp
|
|
AGC
|
Auto/ Manual
|
|
S/N Ratio
|
≥ 55 dB
|
|
BLC, HLC, Smart defog
|
ON/OFF
|
|
WDR
|
120dB
|
|
Day& Night
|
ICR
|
|
Digital Zoom
|
16x
|
|
Privacy Masking
|
24 privacy masks programmable; optional multiple colors and mosaics
|
|
Auto Focus
|
Auto/ Semi-automatic/ Manual
|
|
Focal Length
|
4.5 mm to 162 mm, 36x
|
|
Zoom Speed
|
Approximately 3.3 s (optical wide to tele)
|
|
Angle of View
|
60.6° to 3.68° (wide to tele)
|
|
Minimum Working Distance
|
10 mm to 1500 mm (wide to tele)
|
|
Aperture Range
|
F/1.6 to F/4.4
|
|
Pan Range
|
360° endless
|
|
Pan Speed
|
Pan manual speed: 0.1° to 160°/s, pan preset speed: 240°/s
|
|
Tilt Range
|
-20°~90°(Auto Flip)
|
|
Tilt Speed
|
Tilt manual speed: 0.1° to 120°/s, tilt preset speed: 200°/s
|
|
Number of Preset
|
300
|
|
Park Action
|
Preset/ Patrol / Pattern/ Pan scan/ Tilt scan/ Random scan/ Frame scan/ Panorama scan
|
|
Smart-tracking
|
Manual/ Panorama/ Intrusion trigger/ Line crossing trigger/ Region entrance trigger/ Region exiting trigger
|
|
IR irradiation distance
|
200m
|
|
IR irradiation angle
|
Automatically adjusted, depending on the zoom ratio
|
|
Alarm Input
|
7 Inputs
|
|
Alarm Output
|
2 Outputs
|
|
Alarm Actions
|
Preset, patrol, pattern, SD/SDHC card recording, relay output, notification on client
|
|
Monitor Output
|
1.0Vp-p / 75Ω, NTSC (or PAL) composite, BNC
|
|
Audio Input
|
1 Mic in/Line in interface. Line input: 2-2.4V[p-p]; output impedance: 1KΩ, ±10%
|
|
Audio Output
|
1 Audio output interface. Line level, impedance: 600Ω
|
|
Ethernet
|
10Base -T, /100Base-TX, RJ45 Connector
|
|
Max.Image Resolution
|
2048 x 1536
|
|
Frame Rate
|
30 @ 2048x1536, 1920x1080, 1280x960, 1280x720, 60 @ 2048x1536,1920x1080, 1280x960, 1280x720 with WDR off
|
|
Image Compression
|
H.264/ MJPEG/ MPEG4, H.264 encoding with Baseline/ Main/ High profile
|
|
ROI encoding
|
Support 24 areas with adjustable levels
|
|
Audio Compression
|
G.711ulaw/G.711alaw/G.726/MP2L2/G.722
|
|
No. of Simultaneous Users
|
Up to 20 users
|
|
Dual Stream, Three-Stream
|
Support
|
|
Mini SD Card
|
Support up to 128GB MicroSD/SDHC/SDXC card. Support Edge recording
|
|
User/Host Level
|
Up to 32 users, 3 Levels: Administrator, Operator, User
|
|
Security Measures
|
User authentication (ID and PW), Host authentication (MAC address), IP address filtering
|
|
RS-485 Protocols
|
HIKVISION, Pelco-P, Pelco-D, self-adaptive
|
|
Menu Language
|
English
|
|
Power Supply
|
24 VAC (-A model); 24 VAC/ PoE+ (-AE model)
|
|
Power Consumption
|
Maximum 60W
|
|
Protection Level
|
IP66 standard, TVS 6,000V lightning protection, surge protection and voltage transient protection
|
|
Dimensions
|
Φ266.6 mm x 365.2 mm
|
|
Weight
|
8 kg
|
