Chi tiết sản phẩm

SNMP Managed Media Converter

  • Mã sản phẩm: SNMP Managed Media Converter
  • Giá: 2.650.000 VNĐ
  • Tình trạng: Còn Hàng
  • Bảo hành : 12 Tháng
  • Lượt xem: 371
  • Bảng giá:
Mô tả
(1). Contents of system The main contents of managed system is listed below : 1.Net manageable module It is the key-unit of the system , used to collect the relational information from the media converters installed in the chassis , and manage the functions of media converters . It has one general 10/100M RJ45 port and one general RS232 console port . 2.Full range of Wintop manageable media converters or other manageable cards. 3.17 slots rack-mounted chassis 19 inch 1U rack-mount chassis , with 17 slots ,can support 1 pc Net manageable module and 16 pcs manageable media converters . Normally it will be installed in center ,so that the user can manage it easily . It has dual power supply ,support NMS function .The fans can be managed . 4.Manageable stand-alone media converters in remote end . (2). Manageable functions over view wView manageable system supports full range of standards such as HTTP,SNMP,TFTP,TELNET …etc .The system has proper interface for each . 1.Support WEB based management Our manageable system supports the management based on WEB . It is easy to be understood and used ,no need install special software , so that it is easier for the users . 2.Support SNMP management Fully support SNMP , the users can manage the relational devices via any operating system , such as HP-OpenView . 3.Support Console management when emergency Support local command-string management via Console port , the users can manage the devices via other networks such as Telephone System , in case the Ethernet networks failed . 4.Support TELNET 5.The software can be upgraded online via TFTP.

Description
(1). Contents of system
The main contents of managed system is listed below :
1.Net manageable module
It is the key-unit of the system , used to collect the relational information from the media converters installed in the chassis , and manage the functions of media converters . It has one general 10/100M RJ45 port and one general RS232 console port .
2.Full range of Wintop manageable media converters or other manageable cards.
3.17 slots rack-mounted chassis
19 inch 1U rack-mount chassis , with 17 slots ,can support 1 pc Net manageable module and 16 pcs manageable media converters . Normally it will be installed in center ,so that the user can manage it easily . It has dual power supply ,support NMS function .The fans can be managed .
4.Manageable stand-alone media converters in remote end .

(2). Manageable functions over view
wView manageable system supports full range of standards such as HTTP,SNMP,TFTP,TELNET …etc .The system has proper interface for each .
1.Support WEB based management
Our manageable system supports the management based on WEB .  It is easy to be understood and used ,no need install special software , so that it is easier for the users .
2.Support SNMP management
Fully support SNMP , the users can manage the relational devices via any operating system , such as HP-OpenView .
3.Support Console management when emergency
Support local command-string management via Console port , the users can manage the devices via other networks such as Telephone System , in case the Ethernet networks failed .
4.Support TELNET
5.The software can be upgraded online via TFTP.



Specifications

Description

Part number

19’’ 2U 17slots rack-mount chassis for managed media converters ,dual power supply with NMS function

YT-81/7-2A

10/100M managed media converters

YT-8110-XXXX-M

Net manageable module

YT-M100
